Application:
Applicable to all types of road lighting: expressway, trunk road, main road, large public buildings or commercial center road, secondary road, branch, residential roads and sidewalks, and can also be used for general building, square, freight yard, landscape and other places of lighting.
New installation or replace the traditional high pressure sodium lamp, high pressure mercury lamp, and metal halide street lamps. etc.
Technical Datas:
| Optical |
| LED Luminance | >24000lm |
| Light Fixture Luminance | >23000lm |
| CCT | 6000±500K |
| CRI | >72 |
| LED | Bridgelux chips |
| Electrical |
| Input Voltage | 90-305V AC, 50/60Hz |
| Power Consumption | ≦205W (of Total System) |
| Power Factor | ≧0.9 |
| Power Efficiency | >92% |
| EMI Grade | EMI Class A |
| Protection | Over Current/Over Voltage/Thunder Protection |
| Luminance Efficacy | >120lm/W |
| Mechanical and System |
| IP Level | IP65 |
| Dimension | 484*328*98 mm |
| Net Weight | 7.7 Kg |
| Heat Solution | Convection |
Photometry:
Operation and Storage Condition:
• Operation Ambient Temperature -30 to +60°C, Relative Humidity 20~90%
• Input Voltage 90-305V AC, 50/60Hz
• Storage Ambient Temperature -40 to +85°C, Relative Humidity 5~95%
• Mounting Height : Suitable for 7-8M height
Our Services:
1.Factory price, large monthly output
2. 5 years warranty, high quality guarantee
3. professional Export service, easy to communicate and save your much time
4.Timely delivery, let you win biggest markets advantage
5.Satisfied After-sales service, to be your reliable supplier
6. any question will be get answer within 12 hours
7. R & D team, welcoem OEM and ODM order
Factory Environment:
Shenzhen LEYOND LIGHTING Co., Ltd. is a high-tech corporation founded in 2005, which is the wholy-owned subsidiary of LIYANG Electronic (HK) limited. We concentrateds and specializes in developing and producing high power LED lighting. Our major products include LED Floodlight, COB Led Spot Light&Ceiling Light,LED Hight Bay light and LED Billboard Light etc.Meantime,We also can supply professional lighting solution and OEM service based on customs’ requirement.
FAQ:
1. What is your price?
Based on your quantity and specification requirement, reasonable and affordable price.
2. How many years warratny?
5 years warranty, 50000 hours lifespan.
3. What is the payment term?
For sample order, we can accept T/T, Paypal, West Union, 100% in advance.
For bulk order, 30% deposit in advance by T/T, 70% balance before shipping.
4. What's your fast delivery time for sample 1-10pcs?
Within 2 day once receive your payment.
5. Can I add my Logo on the product label?
Yes.
6. I don’t know how many Led High Bay Light should I use, can you advise?
Yes, we can help you do the lighting design using software Dialux, IES file is available if you have the design team.
